FPGA 夾層卡 (FMC) 產品一覽
|
Datasheet | ||||||||
|---|---|---|---|---|---|---|---|---|
 |
FMC104 | Analog Input | 4 | 250 Msps | 14-bit | LVCMOS/LVDS | LPC | Download |
 |
FMC108 | Analog Input | 8 | 250 Msps | 14-bit | LVCMOS/LVDS | HPC | Download |
 |
FMC110 |
Analog Input and Analog Output |
2 in, 2 out | 1000 Msps input, 1250 Msps output |
12-bit, 16-bit |
LVDS | HPC | Download |
 |
FMC112 | Analog Input | 12 | 125 Msps | 14-bit | LVDS | LPC | Download |
| |
FMC116 | Analog Input | 16 | 125 Msps | 14-bit | LVDS | HPC | Download |
 |
FMC120 | Analog Input and Analog Output | 4 in, 4 out | 1000 Msps input, 1250 Msps output |
16-bit | JESD204B | HPC | Download |
 |
FMC121 | Analog Input and Analog Output | 2 in, 2 out | 1000 Msps input, 1400 Msps output |
16-bit | JESD204B | HPC | Download |
 |
FMC122 | Analog Input | 1, 2 | 2500 Msps (1 Ch), 1250 Msps (2 Ch) |
8-bit | LVDS | LPC | Download |
 |
FMC123 | Analog Input | 4 | 1000 Msps | 16-bit | JESD204B | LPC | Download |
 |
FMC125 | Analog Input | 1, 2, 4 | 5000 Msps (1 Ch), 2500 Msps (2 Ch), 1250 Msps (4 Ch) |
8-bit | LVDS | HPC | Download |
 |
FMC126 | Analog Input | 1, 2, 4 | 5000 Msps (1 Ch), 2500 Msps (2 Ch), 1250 Msps (4 Ch) |
10-bit | LVDS | HPC | Download |
 |
FMC134 | Analog Input | 2, 4 | 6400 Msps (2 Ch), 3200 Msps (4 Ch) |
12-bit | JESD204B | HSPC (FMC+) | Download |
 |
FMC140 | Analog Input | 4 | 370 Msps | 16-bit | LVDS | HPC | Download |
 |
FMC142 | Analog Input and Analog Output | 2 in, 2 out | 370 Msps input, 2500 Msps output |
16-bit | JESD204B | HPC | Download |
 |
FMC144 | Analog Input and Analog Output | 4 in, 4 out | 370 Msps input, 2500 Msps output |
16-bit | JESD204B | HPC | Download |
 |
FMC150 | Analog Input and Analog Output | 2 in, 2 out | 250 Msps input, 800 Msps output |
14-bit, 16-bit |
LVDS | LPC | Download |
 |
FMC151 | Analog Input and Analog Output | 2 in, 2 out | 250 Msps input, 800 Msps output |
14-bit, 16-bit |
LVDS | LPC | Download |
 |
FMC160 | Analog Input and Analog Output | 1 in, 1 out, 2 in | 3600 Msps input (1 Ch), 1800 Msps input (2 Ch), 2850 Msps output |
12-bit, 14-bit |
LVDS | HPC | Download |
 |
FMC161 | Analog Input | 1, 2 | 3600 Msps (1 Ch), 1800 Msps (2 Ch) | 12-bit | LVDS | HPC | Download |
 |
FMC163 | Analog Input and Analog Output | 1 in, 1 out, 2 in | 2850 Msps output, 4000 Msps input (1 Ch), 2000 Msps input (2 Ch) |
12 in, 14 out | LVDS | HPC | Download |
 |
FMC164 | Analog Input | 4 | 250 Msps | 16-bit | LVDS | LPC | Download |
 |
FMC168 | Analog Input | 8 | 250 Msps | 16-bit | LVDS | HPC | Download |
 |
FMC170 | Analog Input and Analog Output | 1 in, 1 out | 5000 Msps input, 5000 Msps output |
10-bit | LVDS | HPC | Download |
 |
FMC172 | Analog Input, Analog Output | 2 | 6.4 GSPS (1 channel), 6.0 GSPS output (1 channel) |
10-bit | LVDS | RF-RF | Download |
 |
FMC176 | Analog Input and Analog Output | 2 out, 4 in | 250 Msps input, 2850 Msps output |
14-bit | JESD204B (in), LVDS (out) | Download | |
 |
FMC204 | Analog Output | 4 | 500 Msps | 16-bit | LVDS | HPC | Download |
 |
FMC216 | Analog Output | 4, 8, 16 | 1250 Msps (4 Ch), 625 Msps (8 Ch), 312.5 Msps (16 Ch) |
16-bit | JESD204B | HPC | Download |
 |
FMC230 | Analog Output | 2 | 2850 Msps | 14-bit | LVDS | HPC | Download |
 |
FMC30RF | Receiver & Transceiver (Analog Input and Output) | 1RX, 1TX | LVDS | LPC | Download | ||
 |
FMC40X | Clock Distribution and Trigger Distribution | 8 trigger out, 8 clock out | LPC | Download | |||
 |
FMC422 | CameraLink Video Interface | 2 | 255MB/s (Base), 510MB/s (Medium), 680MB/s (Full) | 24-bit (Base), 48-bit (Medium), 64-bit (Full) | HPC | Download | |
 |
FMC424 | Digital Communications | 2 | 40 Gbps | GBT | HPC | Download | |
 |
FMC430 | Digital Communications | 2 | GBT | LPC | Download | ||
 |
FMC667 | Digital Signal Processor | HPC | Download |
