隨時隨地學習 量測知識



量測是每個電子、電機科系的師生都需要會的基本技巧,以往的量測數據仰賴著大型的量測儀器,需要進入實驗室等場域才能進行,但是現在不需要了,如果您擁有Digilent的口袋儀器實驗室系列,透過多合一的小型儀器,便可立即量測、產生、紀錄與控制各種混合訊號電路,可替代許多實驗室設備,讓您的電腦瞬間變成功能強大的電路學習平台。搭配免費的軟體,使您可以在任何需要工作的地方皆可立即輕鬆建立、測試電路!

使用 Analog Discovery 2 學習基礎量測



Digilent Analog Discovery 2 是一個迷你型 USB 示波器和多功能儀器,可以測量、讀取、生成、記錄和控制各種混合訊號電路。本系列影片由北京郵電大學與DIGILENT合作錄製而成的產學合作課程,影片內容詳細介紹了 Analog Discovery 2的各項儀器功能及實驗操作。可配合《工程導論》、《電路原理》、《模擬電子線路》、《信號與系統》、《虛擬儀器技術與應用》等課程的教學實驗,培養學生加強實驗操作、理論學習理解的能力。

(遠端實驗)產學合作明星課-北京郵電大學AD2教程 >>

多合一的儀器功能

Developed in conjunction with Analog Devices and supported by Xilinx University Program. This test and measurement device is small enough to fit in your pocket, but powerful enough to replace a stack of lab equipment, providing engineering professionals, students, hobbyists. and electronic enthusiasts the freedom to work with analog and digital circuits in virtually any environment, in or out of the lab. The analog and digital inputs and outputs can be connected to a circuit using simple wire probes; alternatively, the Analog Discovery BNC Adapter and BNC probes can be used to connect and utilize the inputs and outputs. Driven by the free WaveForms software (Mac, Linux, and Windows compatible), Analog Discovery 2 can be configured to work as any one of several traditional test and measurement instruments including an Oscilloscope, Waveform Generator, Power Supply, Voltmeter, Data Logger, Logic Analyzer, Pattern Generator, Static I/O, Spectrum Analyzer, Network Analyzer, Impedance Analyzer, and Protocol Analyzer.

免費的軟體支援

WaveForms is the free software application that comes with the Analog Discovery 2 and enables the use of the available analog and digital instruments. The software has been refined by customer feedback for over 10 years and features a computer and laptop friendly user interface that has the feel of traditional benchtop equipment. The Analog Discovery 2 communicates with WaveForms via a USB connection to your computer, allowing users to capture, record, analyze and generate mixed signal and mixed domain waveforms. WaveForms can be downloaded and installed in under 60 seconds and can be tested without hardware using its demo mode feature. In addition to the use of the instruments in the application, WaveForms has a script editor tool, which allows custom scripting of the instruments in JavaScript.

Operating System Compatibility: WaveForms is designed to be run on a laptop or desktop computer and is Mac, Windows, and Linux compatible. More information on specific operating system details can be found on the WaveForms resource center. Questions about compatibility and operating systems should be directed to the Digilent Forum.

DIGILENT x 北京郵電大學 x 產學合作課

01

單元 1:電壓源與電壓表

Unit 1
02

單元2: 函數產生器的基礎

Unit 2
03

單元3: 示波器基礎

Unit 3
04

單元4: 示波器進階

Unit 4
04

單元5: 函數產生器進階

Unit 5
06

單元6: 感測器除錯

Unit 6
07

單元7: 頻譜分析儀的使用

Unit 7
08

單元8: 網路分析儀的使用

Unit 8

更多有關 Analog Discovery 2 用於量測教學與應用,請與我們聯繫
